The machine uses foldout elements to applicate for the FIBC folding. After blowing the bag through the fan, open filling spout (in order to discharge unwanted air out in course of folding FIBC), and to fold FIBC by air vat. The machine can improve work efficiency, reduce personal labor intensity and reduce cost.
The appearance of folded FIBC is consistent and beautiful.
The machine can done one time's folding work in 10-20 sec.
| Item | Jumbo Bag Folding Machine |
| Model | BFM 120 |
| Type | Pneumatic Open-close, Blowing and Folding |
| Description | |
| Folding Guide Device | SS 304 Grade sheet |
| Blowing system | 2.2kw/3hp high pressure blower |
| Air Filter | SS304 50 Micron Filter |
| Rest of Body | M.S., S.S.304 with Powder Coating |
| Minimum Dimensions of the Bag | 60cm x 60cm |
| Maximum Dimensions of the Bag | 110cm x 110cm |
| Working Distance | 1200mm |
| Length Range of the Bag | Max. Up to 160cm |
| Work Area Size | 160 x 120cm |
| Air pressure | 7 to 8 bar |
| Operating | Semi Automatic electrical panel |
