| Production capacity 180 Pieces / Hour | (Full sealing in one operation) |
| Materials to be processed | Tubular Lay Flat Film |
| Low – Density polyethylene | 40-200 micron |
| Maximum Liner Width | 2200 mm |
| Minimum liner width | 1100 mm |
| L shape spout | L shape sealing (Single Die type) |
| Suspended sealing | U shape sealing (Single Die type) |
| Bottom sealing | Straight sealing (Single Die type) |
| Rack system for open hot Sealing type | |
| L spout + Suspended sealing | Temperature-controlled sealing die |
| Bottom sealing | temperature-controlled sealing die |
| Spout Length (fixed) standard | 700mm / fixed (should be specified) |
| Neck angel length | 700mm / fixed (should be specified) |
| Conic length | 300mm (should be specified drawing) |
| L shape sealing Angle | 90°-degree standard |
| Length of the film (body length) | Adjustable min. 500 to max. 3000mm |
| L shape spout / Suspended Diameter | Adjustable between 200 to 800mm, max. |
| U Shape sealing length | As per your size (should be specified) |
| Bottom sealing distance | Fixed |
| Width of the weld (sealing) | 10mm |
| Ventilation Punch Star / round punch both side | |
| Machine control by | PLC (programmable) with 10” HMI |
| Servo motor 2.0kw and its drive - 1 set | Servo motor 1.0kw and its drive - 1 set |
| (Fuji/Mitsubishi ElectricMake) | Gearbox + motor 2hp and its A/C drive - 1 set |
| HMI Make | Fuji/Schneider Electric Make |
| PLC Make | Fuji Electric Make |
| Temperature controllers | MULTISPAN (firm 48 X 48) |
| Electrical | Main panel 1 no |
